FS-130萬能粉碎機
所屬分類：粉碎機
- 點擊次數：
- 發布日期：2015/05/26
- 在線詢價
詳細介紹
主要用途 Main application
本機適用于制藥、化工、食品行業，是微粉碎加工前道工序的配套設備，它不受物料粘度、硬度、軟度及纖維等限制，對任何物料都能起到較好的粉碎作用。
This machine is applied as supporting equipment，before crushing process in trades as pharmaceutical，chemical and foodstuff etc,which has better crushing effect for any material without limitaion on its viscosity,hadness,softness and fiber etc.
工作原理 Working principle
本機為立式結構，物料由進料斗進入粉碎室，利用旋轉刀旋轉沖擊，固定到和活動刀同時剪貼而獲得粉碎，經旋轉離心力的作用，物料自動流向出口處。另外，WCSJ-20按“GMP”標準設計，本機全部采用不銹鋼材料制造，使藥品、食品等能符合國家衛生要求。
Thia machine is of vertical crushing structure，and the material is fed into the crushing chamber through a hopper，crushed by simultaneous cutting of both fixed and movable knives and rotating impact of rotating knife，and flowed to the exit automatically under the effect of rotating cen trifugal force besides.WCSJ20 is designed according to GMP standard and wholly made of stainless steel, making the machine and food met the national hygienic requirement.
Universal course crusher
主要用途 Main application
本機適用于制藥、化工、食品行業，是微粉碎加工前道工序的配套設備，它不受物料粘度、硬度、軟度及纖維等限制，對任何物料都能起到較好的粉碎作用。
This machine is applied as supporting equipment，before crushing process in trades as pharmaceutical，chemical and foodstuff etc,which has better crushing effect for any material without limitaion on its viscosity,hadness,softness and fiber etc.
工作原理 Working principle
本機為立式結構，物料由進料斗進入粉碎室，利用旋轉刀旋轉沖擊，固定到和活動刀同時剪貼而獲得粉碎，經旋轉離心力的作用，物料自動流向出口處。另外，WCSJ-20按“GMP”標準設計，本機全部采用不銹鋼材料制造，使藥品、食品等能符合國家衛生要求。
Thia machine is of vertical crushing structure，and the material is fed into the crushing chamber through a hopper，crushed by simultaneous cutting of both fixed and movable knives and rotating impact of rotating knife，and flowed to the exit automatically under the effect of rotating cen trifugal force besides.WCSJ20 is designed according to GMP standard and wholly made of stainless steel, making the machine and food met the national hygienic requirement.
技術參數 Technical parameters
|
參數名稱 型號 |
130B 型 |
180B 型 |
250B 型 |
320B 型 |
|
主軸轉速 (r/min) |
7000 |
7000 |
3800 |
3800 |
|
生產能力 (kg/h) |
2~5 |
10~30 |
50~250 |
80~300 |
|
配用電機 (kw) |
1.1 |
2.2 |
5.5 |
7.5 |
|
粉碎細度 ( 目 ) |
10~120 |
|||
|
工作噪音 ( 分貝 ) |
≤ 85 |
|||
|
外形尺寸 (mm) |
560*350*820 |
690*520*1000 |
880*520*1360 |
950*520*1450 |
|
重量 (kg) |
75 |
85 |
220 |
250 |
